Design heat load in residental building (example for the lesson)
Jump to navigation
Jump to search
| Product | InstalSystem 5 |
| Type of article | SAMPLE PROJECT |
| Source for translation | 2020-02-23 |
Project description
This article presents a project file with calculation of design heat load in residental building.
The project is an example for the following lesson: Calculation of design heat load of rooms. The lesson describes how to make such a project step by step.
Files to download and project information
| Project files
|
Initial state, isproj Partition definitions, isproj Design heat load in residental building, isproj |
| Designed with | InstalSystem 5 Rev. 23.0 |
| Required modules | Base module Heat loss |
| Project range | Thermal calculations of building |
| Used catalogues |
Climatic data: Poland |
| Type of building | residental building with basement 4-storey |
| Building structure | - |
| Drawings range | Plan view |
| Prepared by |  www.instalsoft.com |
| Legal disclaimer | Copying of entire project and of its fragments allowed |
| Calculation results | Full printout, xls Full printout, pdf |
| Drawing results | - |
